The author appreciates his colleagues at Siargao Ltd., who have been dedicated to the challenges and innovations in the commercialization of microfluidic sensing devices since 2009. Other special effects such as evaporation must be considered, especially when approaching nanoliter per minute flowrates. The research data for the current microfluidic market have excluded the inkjet applications, addressing only the diagnostic devices and pharmaceutical and life science tools [27]. The hot wire uses a resistor as heater and sensing element. These sensors can monitor gas or oil flows without any specific calibration. The existing sensor products on the market also have some unsolved reliability issues in applications. Electrochemical sensors are mostly studied and often composed of several electrodes that are easy to fabricate together with the microchannels. Besides, the majority of microfluidic processes are water-based. Nevertheless it requires knowledge of the fluid density and specific heat capacity. Therefore, a primary standard or a reference defined by an international norm governs the manufacture of a flow sensing product with specific sensing technology. Precision control of drug delivery is getting increasing attention in recent years. Optical or image processing would help understand the physical or even chemical process, but it would not help improve the flow measurement accuracy. In another study, [63] a SAW sensor with dual symmetrical IDTs made on a 30mm by 30mm square quartz crystal substrate was used to measure the flowrate in a designed channel by recording the delay times and the corresponding frequencies. These two temperature sensors can be simple resistors of identical resistance values or identical thermal-piles. For example, one report [82] tested the reproducibility of several commercial calorimetric flow sensors of the identical model for the time dependence in water. Several efforts to establish a primary standard or a traceable reference system for flow metrology in microfluidics applications have been made in the past years [35, 36, 37]. These data are similar to the analog ones in the electronic age. The pressure effects of compressibility can be considered secondary. Most of the devices available are based on colorimetric or optical images or limited electrical signals. However, for microfluidic measurement, the opening will be detrimental once the liquid-filled up the cavity underneath the membrane. Left - Example of the response of a micromachined thermal time-of-flight sensor to air bubbles passing in a DI-water microfluidic channel; and right shows the same sensor response at 20mL/min flow to the channel conditions: A as calibrated DI water; B tested after sensor powered on in a null flow DI water channel for 48 hours; C After B test and degassing for 15 minutes; D after C and full scale full (30mL/min) flow for 30 minutes; E after D, the channel dried with N2 and re-test. In an earlier report, [94] a thermal time-of-flight sensor with dual sensing elements suspended in a micromachined microchannel showed a dynamic range of 1000:1 could be achieved. It applies to the devices that process fluids at a dimension below the millimeter scale, and the maximum fluidic volume is within milliliters. Optical flow sensing is attractive to the microfluidic application for its non-invasive and high accuracy features. The majority of the current micromachined commercial thermal flow sensors are utilizing the calorimetric principle. The miscible fluids will result in a fluid with a new concentration, while the immiscible fluids will lead to a Two-phasefluid. The microheater and the sensing elements all have the fluidic dependent response that needs to be removed for the complicated fluids. Its based on principles of collaboration, unobstructed discovery, and, most importantly, scientific progression. flow elveflow mfs microfluidic sensors sensor The detailed analyses of the DNA samples become possible. The main flow control solutions can be divided in three sections: pressure based solutions (such as the Flow EZ), volume displacement (such as syringe or peristaltic pumps) and passive techniques. For the same reason, the temperature compensation scheme for the anemometry is more complicated than that for the calorimetry. These sensors normally require a higher power to ensure the heat transfer resulting in a small dynamic measurement range and a low accuracy towards the low measurement end. The high cost of the measuring tube manufacture sparked the attempt with micromachining, and the first research paper was published in 1997 [55]. This website uses cookies to improve your experience. The concentration of the dual miscible fluids can be deduced from the thermal properties measured by comparing the data in the registers at the calibration.

In a microscale optical flow sensor report, [75] an optical fiber structure was fabricated in the form of a drag force cantilever to measure the microfluidic flow. The interactions between fluid medium and flow channel surface or the surface tension, cavitation, dissolution, and others play critical roles in microfluidic flow metrology. The flow metering at the microfluidic scale is quite different from those in a large pipeline.

Many studies proposed integrating flow sensors into the microfluidic system. The Organs-on-chips[5] approaches utilize microfluidic devices to culture living cells for modeling physiological functions of tissues and organs, making microfluidics a unique tool to enrich our understanding of life sciences and to assist the research and assembly of new drugs. Such pressure is not necessarily existing in the microfluid subject to measurement. A mechanical system, usually actuated by an electrical stepper motor, pushes the syringe filled with liquid at a fixed rate.

Even with the miscible fluids, the microbubbles would likely present in all cases. Figure 2 shows a typical structure of a micromachined thermal time-of-flight sensor chip [53].

For controlling the flow, the main solutions, in microfluidics, are mechanical or pressure based. However, it can also be utilized for industrial processing in classic fluidic dynamics. For example, a 10~15m parylene conformal layer will provide the properties of the good material of stiffness and robustness for the application. Example of a micromachined thermal time-of-flight sensing chip: (a) optical photo of the chip, top view; (b) cross-section schematic. The microfluidic flow in the perpendicular directions will displace the fiber cantilever tip, causing the light intensity change at the aligned receiver. The reservoir is connected to the microfluidic chip via a tube. In the dimension of a microfluidic channel, the surface area relative to the volume is dramatically larger than those in a large pipe. Some efforts were also made to measure the flowrate with the SAW devices. microfluidic bubble microfluidics detector elveflow flow thermal sensor darwin trap mfs The resistance being dependent on the temperature, a relationship between applied tension, temperature and resultant resistance can be established. Such a task is still at an earlier stage, and additional time will be need before the standards become available. Therefore when a flow sensor calibrated at a cavitation-free condition is applied to measure a cavitating flow, the measurement deviations will be inevitable. Choosing the right microfluidic flow meter adapted to the flow regime and fluid is critical for accurate measurements. Cavitation is often known as a detrimental phenomenon in high-speed flows that leads to mechanical damages at the flow path. The user is able to signal average for data smoothing if desired,and the user can select how frequently the flow rate values are recorded in the data file. By observing the heat distribution over time, it is able to deduce the fluid velocity and thus the flow rate. The removal of cavitation can be done with properly designed materials for the microfluidic channels [83, 84, 85, 86]. The measured changes in the amplitude are directly proportional to the heat transfer between the microheater and the sensing elements that will provide the mass flowrate similar to the calorimetric or anemometric approach per the data acquisition process. The changes in the mixtures density and physical properties will lead to completely different heat and mass transfer, which will significantly deviate the metering values that are always reference to those at the calibration conditions. In this scope, both flow and pressure sensors have been extensively studied [28]. The user no longer has to calibrate or evaluate the fluidic resistance of its system, but can rely on a feedback loop to control the flow. Researches on microfluidic flow sensing approaches are for miniaturized, cost-effective, and integrable products. Therefore, it has the advantage of a pure velocity measurement independent of the fluidic properties.

The widely adapted primary standards are the gravimetric and volumetric principle. These commercial products utilize different thermal sensing principles [41, 42, 43] that cover the three major technologies with thermal calorimetry, anemometry, and thermal time-of-flight approaches. The flow rate or the pressure range you need. Before the form factor, cost, and reliability issues can be solved, large scale applications are still not possible. The ECO Flow Meter offers the same performance as the Standard model, but as it does not havea display screen and interface buttons, it can only be controlled through a computer. The first micromachined thermal flow sensor made for microfluid is used in micro gas chromatography [4]. Another advantage for the MEMS Coriolis mass flow sensor is that it usually operates at a much higher resonant frequency with substantially less vibratory influences from the environments than those for the traditional Coriolis mass flow technology. In biological experiments, the presence of cells or particles in the fluid might affect the fluid properties and affect the measurement. The changes of the tube oscillation in time and space are a direct measure of the mass flow. Nevertheless, the stability of this system can be quite bad due to internal friction and the functioning principle itself. These package approaches are also similar to the traditional capillary thermal mass flow sensors, where the hot wires are winded onto the surface of a special stainless tube. However, due to its system issues, its progress is less pronounced. The main advantage of Coriolis mass flow meter is the independency between the measured flow rate and the properties of the liquid. The time-domain data yield additional information, which allows the acquisition of additional fluidic thermal dynamic properties such as thermal conductivity and specific heat. Therefore, although the micromachined Coriolis sensors demonstration has been over two decades, the applications are still very limited. Fortunately, microfluidics growth is parallel with the significant advancement in the MEMS and LSI/VLSI IC industry. Live flow monitoring can be achieved using flow sensors. The mechanical deflection can be read out with an optical microscope or photodiode. However, many of these technologies are bulky, costly, and not easily integrated with the microfluidic channels. In the microfluidic flow measurement, the liquid is generally non-compressible. The standalone or large scale commercial applications are yet to emerge. In a most recent review, [95] many available technologies can be used to acquire the microfluidic thermodynamic properties such as viscosity, density, diffusion coefficient, solubility, and phase equilibrium directly from the microfluidic channels on a chip. An integrated micro-cantilever inside the microfluidic channel via the microfluidic favorable PDMS process achieved a capability of detecting 200L/min flowrate but only have a small 5:1 dynamic range [68]. Several key components, including microfluidic channels, microvalves, micropumps, needles, mixers, and sensors, are considered the necessary ones for the desired microfluidic chip or system. In a way, associating a pressure source with a flow rate sensor combines the main strengths of syringe pumps and pressure solutions. Therefore, it is of interest to have additional measurement approaches that can alert in situwhen the cavitation is present in microfluidics. For sub microliter per minute flowrates, laser interferometry has been used as an alternative precise reference for the desired accuracy [38].

Many factors that may be trivial in the conventional fluidic dynamics become critical for microfluidic metrology. The detailed theoretical interpretation and governing physics can be found in the literature as well as the international standard [1, 46]. Most MEMS foundries have the necessary equipment for manufacturing such sensors, which allows a very favorable cost and makes it possible for high volume applications. IBM first reported the inkjet printer heads [3] in 1977, and now millions of such units have been shipped worldwide, enabling color printing into every corner of human life. Therefore, if the sensor only has a microheater and a sensing element pair, the measurement will still be dependent on the flow medium properties.
